TRI26 IPC — Improved Pitch Control

Democratizing
marine exploration.

8-Thruster Array
TALON v2 Claw
Triple Camera System
Modular Electronics Enclosure
Generatively Designed Tether Relief
3D Printed Frame

Meet
TRI26

A competition-grade underwater vehicle engineered for full 6-DOF control, triple-camera situational awareness, and modular mission adaptability.

01Thruster Config8× TD1.2 — full 6-DOF
02ClawTALON v2 — 2DoF dual-servo
03Vision3× ExploreHD 3.0
04Enclosure110×300mm sealed cylinder
05Tether Relief100N rated, SF 5
06Frame3D printed PETG
Technical Specifications
01Mass6.2 kg
02Thrusters8× TD1.2 (4 vertical, 4 horizontal at 30°)
03Cameras3× ExploreHD 3.0
04Enclosure110mm × 300mm sealed cylinder
05Tether15m, Cat6 + 10AWG, neutrally buoyant
06DoF6 (full)

TALON v2 —
Built to grip anything.

A 2DoF end-effector designed for the MATE ROV task pool. Dual-servo articulation means the claw rotates independently of the ROV — no repositioning required. Tool-free field swaps and a built-in camera mount, all in a package that attaches with two M3 screws.

2Degrees of Freedom
4NmPeak Torque
2M3 Screws
012DoF ArticulationOne servo for grip, one for rotation
02Peak Torque4Nm per servo — ROVmaker SV40
03TPU Compliance PadsRemovable, collapsible — underwater grip
04Modular Gripper HeadSwappable shapes and sizes
05Tool-free SwapMounts and dismounts with 2 M3 screws
06Camera MountDoubles as downward ExploreHD mount
MMT — Mission Management Terminal — LIVE
● ACTIVE
02:43:38
5/24/2026
PRACTICE RUN #1
(W/O UPGRADE)
Project Trident logo
TIME REMAINING: 12:40
TRANSECT00:11 / 00:50
SESSION Δ:-00:02
EST PTS: 230/270
TASKTIME(PLT)
PROCESSING
CALCULATION
SCALE
PHOTOGRAMETRY
CORAL #1
CORAL #2
TRANSECT
CORAL #3
CORAL #4
ICEBERG
TASK #12
00:24 / 00:20
00:31 / 00:40
01:12 / 01:20
00:11 / 00:50
__:__ / 00:50
__:__ / 00:20
__:__ / 00:35
__:__ / 00:40

MMT.
Built for the Crew,
Not Just the Pilot.

The Mission Management Terminal — a real-time crew coordination system built from scratch for competitive ROV operations.

Capabilities

Every decision in the water is a time decision. MMT eliminates the ambiguity — both operators see the same state, the same clock, the same prediction.

Paired with
VITURE XR
COCKPIT UI
01
Orchestrate the whole crew
MMT displays the full mission task list in real time, showing task status and outcome predictions for both the pilot and engineer simultaneously. No ambiguous verbal calls. No decision lag.
02
Strategic optimization
Every run is logged. After each session, the team reviews task sequencing, completion rates, and point yield to refine strategy. MMT turns every practice run into data.
03
Built on aviation logic
Inspired by the Flight Management Computer (FMC) used in commercial aviation. The same principle: reduce cognitive overhead so operators focus entirely on execution.
04
Paired with XR
The pilot runs MMT and Pilot UI through VITURE XR glasses — an immersive, expanded display that renders depth, attitude, camera feeds, and mission state at a scale a laptop screen never could.

Custom-built by Project Trident. Not a plugin. Not a dashboard template.

OpenBot

An open-source vehicle interface developed by Project Trident. In collaboration with Whalefall, OpenBot enables real-world data collection deployments beyond the competition pool.

01
Open SourceOpen-source vehicle interface developed by Project Trident
02
CollaborationWhalefall partnership enables real-world data collection
03
Global ReachProviding opportunities to apply engineering around the world

"Providing opportunities to apply engineering around the world."

DEPTH
Who we are

A first-year team. A production-grade vehicle.

Ranked #4 at the 2026 MATE ROV Regional — Explorer Class. First year. First competition. Top four.

MATE ROV 2026 — REGIONALEXPLORER CLASS
BERRYBOTICS476.7PTS#1
PROJECT BOTICS469.0PTS#2
KEPLER ROBOTICS377.8PTS#3
PROJECT TRIDENT369.7PTS#4
PIRATECHNOLOGIES357.3PTS#5
MEGALODON ROV345.9PTS#6
GLACIER POINT337.8PTS#7
PRELIMINARY RANKINGS● LIVE
What we build

Project Trident is a student-led engineering company based in Danville, California. Founded by six core members at The Athenian School, the company has grown to 15 engineers, designers, and operators united by a single mission: to build technology that makes the ocean more accessible. From a custom ROV to an open-source vehicle interface deployed in real-world research, Project Trident approaches every problem the way a professional engineering team would — with iteration, precision, and a bias toward building things that actually work.

15Students
6Degrees of Freedom
1stYear Competing

Backed by
people who build.

Project Trident is supported by partners who help turn prototypes into working systems, practice hours into performance, and student engineering into something real.

The people
behind the machine.

Max Mao portrait

CEO

Max Mao

David Chen portrait

CTO

David Chen

Ariel Grossberg portrait

COO

Ariel Grossberg

Subteams
Software
Fabrication
Design
Operations
CLASSIFIED — PROJECT TRIDENT

TRI27

COMING 2027

TRI26 IPC demonstrated that a first-year team can build a production-grade ROV from scratch. TRI27 begins where IPC left off — deeper autonomy, a more capable vision system, and a platform designed to scale.

Program StatusEARLY DEVELOPMENT
Autonomy
[DETAILS PENDING]
Vision
[DETAILS PENDING]
Platform
[DETAILS PENDING]
